Sunalta Square
Designed by Gravity’s sister company Inertia Residential Design.
Sunalta Square is a four unit ground-oriented townhouse building in the South of Calgary's Sunalta community just east of Royal Sunalta Park. It gets its name because, compared to it’s sister project, it’s on a rectangular parcel.
The facades are distinguished with two large blocks of divided warehouse-style windows. Each of these is surrounded by the steel shadow box which at once provides shade to the interior and gives the window a strong shadow line on the principal mass of the building. The heavy steel motif reappears in the canopy over the entry doors.
The floorplan is a “foursquare” layout with front and rear unit plans being mirrored on a spine.
The four units each have a single garaged parking stall and together achieve a density of just over 66 units per hectare.
| Number of Units | 4 |
| Total Floor Area | 6203 SF |
| Efficiency | 100% |
| FSR/FAR | 0.96 |
| UPH | 66.3 |
| On Site Parking | 5 |
Build: RNDSQR
Design: Inertia Residential Design
Photography: Gary Campbell
Completion: 2018
Key Plan
Site Plan
